Measure BIG, carry small.

The world’s smallest wireless multimeter, DSO and logger

Pokit Meter

Name: Pokit Meter
Brand: Pokit Innovations
SKU: POK-BLK
Price: 98.0 USD
Availability: InStock
Rating: 4.73 (51 reviews)

$ 98.00 USD

Colour:

Black

Variant

Quantity:

Ultra-Compact, fits on your keychain
60VDC/42VAC (RMS), 2A
Measures AC/DC voltage, AC/DC current, resistance, temperature, continuity check, and diode check
Connects wirelessly to your smart device
Connect up to 4 devices for non-synchronous multi-channel access
Retractable probes and leads
Precision user calibratable
Ultra-Low power with replaceable coin cell
1-year warranty, 30-day money-back guarantee (T&Cs Apply)

Core App Modules (Included):

Multimeter
Oscilloscope
Spectrum Analyser
Data Logger

Specifications

Click here for full specifications list

Multimeter

Voltage: 10mV to 60V DC, 42V AC (True RMS), ±1%
Current: 1mA to 2A max, ±1%
True RMS Frequency: 40 to 100Hz
Resistance: 1 to 1M Ohm, ±5%
Temperature: 0°C to 60°C ±1%°C, 32°F to 140°F ±1.8°F
Diode Check: Check Only
Continuity Check: Yes
Continuity Check Delay (max): 200ms
Continuity Buzzer: App Only
True RMS: Yes

Oscilloscope

Voltage: 10mV to 60Vpk, 42V AC (RMS)
Current: 1mA to 2A max
DC Accuracy: ±1%
Analog Bandwidth: -3dB @ 200kHz
Sampling: 12bit, 1M sample/sec
Input Impedance (DC): 1M Ohm

Logger
Logged Parameters: Voltage, Current, Temperature
Logging: 12kB, 45min/sample @ 6 months
Sample Rate: 1sec to 1hr

Modules

Included:

Multimeter
Oscilloscope
Data Logger
Spectrum Analyser

Additional:

Coming soon

What's in The Box

Pokit Meter
Carry pouch
Wire grip probes
Battery
Spare fuse

Shipping

Shipping times and costs are estimated at checkout, and vary depending on destination country and if Postal or Express shipping is chosen.

VAT/import tax is not included unless stated otherwise during checkout.

See full list of regions/countries in our Shipping Policy.

The Pokit Meter Advantage

Ultra-Compact

Engineered to be compact and portable, perfect for working in tight spaces or on-the-go.

Versatile

A complete suite of measurement tools in your pocket, ensuring you’re never without the tools you need.

Precise

Accurate and calibratable, delivering dependable precision.

One App to Rule Them All

The Pokit App seamlessly integrates multiple measurement tools into one intuitive platform, all accessible from your smart device.

Core App Modules

Pokit Meter seamlessly integrates with a suite of powerful app modules, each unlocking an essential measurement capability. With Pokit Meter, you have all the measurement power you need—right in the palm of your hand.

View all

Multimeter

Oscilloscope

Data Logger

Spectrum Analyser

Which Pokit Are You?

What's New

Bundle and Save

The Ultimate Tool For Students!

Gary Davies: Pokit Meter Review

What People Are Saying

Performs as expected

Portable and versatile. Does what I need it to do. The maximum voltage warning should be more flashy.

Impressive, very useful

Best use of a coin battery ever, it's an amazing little device useful for a lot of things. It has its limitations but it's still worth every penny.

nice toy with restrictions

this is not all roses. It's a nice gadget. The biggest disappointment for me was that the ossciloscope only makes a snippet display once you push a button on your phone. It does not continuously show you what is going on. Especially for an oscilloscope that is *very* unhandy.
Where the voltmeter does give continuous reading.. i ask WHY??

Hello Jan,

Pokit Meter isn’t capable of doing continuous oscilloscope measurements because due to the chemistry the coin cell battery is only capable of delivering the current required to take a measurement every now and then and not continuously (multimeter only takes a very short measurement once every second).
Also it would very quickly drain the battery.

This is something we have addressed with Pokit Pro because it has a LiPo rechargeable battery, it can deliver the necessary current and be recharged when it runs out.

1 2 3

Customer Service

Contact the Pokit Support Team for any support requests. Submit a support request here.

Pokit Forum

See what the Pokit community is saying on the Pokit Forum. Join the discussion here.

Compact and very user friendly

Useful kit

I‘m a hobbyist who engages in the repair-movement and bought the Pokit pro more or less out of curiosity. Also because I wanted t to reduce the amount of stuff that I carry to repair events.
Turns out the Pokit is a very useful addition to my bag. It works flawlessly and has a good range of features while being very compact.
The only criticism that I have is that the fuse, which (as with all multimeters) easily blows, is a little tricky to replace without doing minor damage to the device.

Pokit Pro

My husband loves it and says it's so much easier to carry around other than the normal big bulky one. Best gift i have ever bought him.
